Bracket
7-34
4st 25/30 2022
8) Removal of Steering Shaft
1. Remove the drive shaft housing assy by referring to
Chapter 7, “Removal of Drive Shaft Housing.”
3. Remove the friction plate bolts 3. (Basic Tiller Handle /
Multi-Function Tiller Handle Models only)
2. Remove the mount bracket 1 and lower rubber mount 2.
4. Install the bolt cover 6.
To Next Page
