Bracket
7-30
4st 25/30 2022
4) Removal of Drive Shaft Housing
1. Prepare a waste oil receptacle under the drain hole,
remove the drain bolt, and drain the oil completely. Refer
to Chapter 3.
2. Remove the bolt 1 and remove the bolt cover 2.
3. Remove the lower mount nut 3 and bolt 4.
4.
Remove the upper rubber mount nuts
5
.
5.
Remove the drive shaft housing
6 and the damper
from
the clamp bracket
assy.
Be careful not to drop the drive shaft housing
during removal from the clamp bracket.
To Next Page
