4
4-31
4st 25/30 2022
8. Inspection Items
1)
Inspection of Fuel Supply System
Check the fuel system piping for fuel leak, dirt,
deterioration and damage, and replace or repair
parts if necessary.
2) Inspection of Filter
1. Check if there is any dirt in fuel filter 1, or if there is any
fuel varnish, debris, deposits and contamination by foreign
matter or water in the fuel filter cup 2, or if there are
any cracks. Wash the fuel filter cup 2 with gasoline, and
replace the filter 1 where necessary.
When removing the fuel filter cup, use a rag to
catch any fuel so there is no spillage.
3 O-ring
Do not reuse.
2. Cleaning of Fuel Tank Filter
Remove the fuel pick up elbow 5 of the fuel tank 4
counterclockwise to remove the part, and clean the filter
6.
3. Cleaning of Fuel Tank 4
Clean the fuel tank 4 if there is any dirt or water.
4 Fuel Tank 5 Fuel Pick Up Elbow
6 Filter
To Next Page
