TOHATSU MFS 25d Service Manual

7-39
4st 25/30 2022
7
4. Check the swivel bracket shaft and other parts for
abnormality, and replace if necessary.
13) Installation of Clamp Bracket
(Manual Tilt Model)
1. Install the clamp bracket in the reverse order of removal.
Distance piece nut 2:
6 N · m (4 lb · ft) [0.6 kgf · m]
Nylon Nut 1:
24 N · m (17 lb · ft) [2.4 kgf · m]
2. Install the thrust rod 3.
Apply sufficient OBM grease to the swivel bracket
shaft.
GREASE
OBMOBM
OBM
