3-5
3
4st 25/30 2022
3) Inspection of Fuel Tank
Remove the four screws from the fuel tank 1, remove the
fuel pick up elbow 2, and clean the filter 3. Remove dirt
and water from the fuel tank if any.
4) Inspection of Fuel Filter
2 Fuel Pick Up Elbow
3 Filter
•
If the red float 1 in the fuel filter is
floating, water has entered. Loosen the
drain valve 2 and squeeze the primer
valve several times to drain the water.
•
Be careful not to spill fuel when removing
the cup 3.
Check the filter 4 for any dirt or buildup of fuel varnish
or debris, and the cup for any cracks or contamination by
foreign matter. Wash the cup with gasoline, and replace
the filter if necessary.
5 O-ring
Do not reuse.
To Next Page
