10
r/min
10
Rigging
r/min
1. Service Information …………………… 10-2
2. Service Data ……………………………… 10-2
1) Boat Mounting Restriction ……………… 10-2
2) Mounting Dimensions …………………… 10-2
3) Transom Dimensions …………………… 10-3
4) Lifting Up the Outboard Motor ………… 10-4
5) Installation of the Outboard Motor ……… 10-4
3. Fuel System ……………………………… 10-6
1) Fuel ……………………………………… 10-6
2) Engine Oil ………………………………… 10-6
3) Installation of the Fuel Tank …………… 10-6
4.
Connections to the Outboard Motor
… 10-7
1) Steering Cable …………………………… 10-7
2) Drag Link ………………………………… 10-8
5. Remote Control Components ……… 10-9
1) Installation of the Remote Control Cable
(Remote Controller Side) ……………… 10-9
2) Installation of the Remote Control Cable
(Engine Side)
Remote Control Model ………………… 10-10
6. Lower Unit ………………………………… 10-15
1) Installation of the Propeller ……………… 10-15
7. Meters ……………………………………… 10-16
1) Installation of Meters …………………… 10-16
8. The Electrical System ………………… 10-17
1) Battery Capacity ………………………… 10-17
2) Installation of the Battery ……………… 10-17
3) Wiring Diagram of the
Remote Controller and Meters ………… 10-18
9. Installation of the Trim Sensor …… 10-20
To Next Page
