TOHATSU MFS 25d Service Manual

2-10
Service Data
4st 25/30 2022
Crankshaft
No.1Metal
MainGallery
OilFilter
No.1
Piston
No.1
CylinderWall
No.1
PistonPin
No.2
Piston
No.2
CylinderWall
No.2
PistonPin
No.3
Piston
No.3
CylinderWall
No.3
PistonPin
No.1
CrankPin
No.2
CrankPin
No.3
CrankPin
Crankshaft
No.3Metal
Crankshaft
No.2Metal
Crankshaft
No.4Metal
OilPan
OilStrainer
CamShaftUpperJournal
OilPressureSwitch
OilPump
CamShaft
Face
RockerArmShaft
RockerArm
OilRegulator
3. Engine Lubrication System Diagram
