10-4
Rigging
r/min
4st 25/30 2022
4) Lifting Up the Outboard Motor
Use an engine hanger.
5) Installation of the Outboard Motor
1. Install the outboard motor so that the interval c between
the anti-ventilation plate a and the hull bottom b is 0 to
25 mm (0 to 1 in).
a: The transom height is the height from the bottom of the
boat hull to the top of transom board.
Adjust the centerline of the template accurately to
the center of the boat transom.
2. Attach an outboard motor mounting template to the boat
transom.
If the mounting height of the outboard motor is too
high, the following may occur.
1) Air may be sucked in through the cooling water
inlet port, and overheating may occur easily.
2)Steering performance deteriorates.
3) When planing, or when the load is heavy, the
propeller tends to idle easily.
To Next Page
