6-12
Lower Unit
4st 25/30 2022
4)
Removal of Water Pump and Cam Rod
1. Loosen the installation bolts in the pump case (upper), and
remove the pump case (upper) 1-2-3-4.
When removing the pump case (lower), insert
flathead screwdrivers into the groove of the case,
and pry slowly to separate the pump case (lower).
3. Loosen the installation bolt in the pump case (lower) and
remove the pump case gasket 6, guide plate 7, guide
plate gasket 8, and pump case (lower) 9.
2. Remove the water pump impeller key 5.
To Next Page
