4.9.4 RS-232C Setting
(1) RS-232C Baud Rate setting (SPEED)
This parameter is to choose a baud rate of the RS-232C interface. When the printer communicates with a
host computer by serial interface, be sure to match the setting with the host.
Notes:
1. When the [FEED] key is pressed, the menu moves in the opposite direction from when the [PAUSE]
key is pressed.
2. When the [FEED] and [PAUSE] keys are simultaneously pressed, the display returns to the system
mode menu.
3. When the [FEED] key or [PAUSE] key is pressed for 0.5 seconds or more during this setting, repeat
mode is enabled and the key pressed is repeatedly entered.
4. The change in the parameter setting becomes effective when the [POWER] key is pressed after
setting, then stored in the backup memory.
(2) RS-232C Parity setting (PARITY)
This parameter is to choose the parity of the RS-232C interface.
Notes:
1. When the [FEED] key is pressed, the menu moves in the opposite direction from when the [PAUSE]
key is pressed.
2. When the [FEED] and [PAUSE] keys are simultaneously pressed, the display returns to the system
mode menu.
3. When the [FEED] key or [PAUSE] key is pressed for 0.5 seconds or more during this setting, repeat
mode is enabled and the key pressed is repeatedly entered.
4. The change in the parameter setting becomes effective when the [POWER] key is pressed after
setting, then stored in the backup memory.
SPEED 9600
SPEED 38400
[FEED]
[PAUSE]
SPEED 19200
9600 bps (Factory default)
38400 bps
19200 bps
SPEED 57600
SPEED 115200
115200 bps
57600 bps
PARITY EVEN
[FEED]
[PAUSE]
SPEED NONE
EVEN (Factory default)
NONE
To Next Page
