4. SYSTEM MODE (For Service Persons and System Administrators) EO13-33005
4.4 Parametr Setting
4- 33
4.4.7 Euro Font Code Setting (EURO CODE)
This setting determines to which code the EURO font code is to be assigned. (Factory default is “B0”.)
Notes:
1. When the [FEED] key is pressed, the menu moves in the opposite direction from when the [PAUSE] key
is pressed.
2. When the [FEED] and [PAUSE] keys are simultaneously pressed, the display returns to the system
mode menu.
3. When the [FEED] key or [PAUSE] key is pressed for 0.5 seconds or more during this parameter setting,
repeat mode is enabled and the key pressed is repeatedly entered.
4. The change in the parameter setting becomes effective when the [POWER] key is pressed after setting,
then stored in the backup memory.
4.4.8 Maxi Code SpecificationSetting (MAXI CODE)
This setting selects a Maxicode specification.
Notes:
1. When the [FEED] key is pressed, the menu moves in the opposite direction from when the [PAUSE] key
is pressed.
2. When the [FEED] and [PAUSE] keys are simultaneously pressed, the display returns to the system
mode menu.
3. When the [FEED] key or [PAUSE] key is pressed for 0.5 seconds or more during this parameter setting,
repeat mode is enabled and the key pressed is repeatedly entered.
4. The change in the parameter setting becomes effective when the [POWER] key is pressed after setting,
then stored in the backup memory.
5. The mode specified by the command in accordance with the status of this parameter is different from the
actual mode. Also, the data transmission method differs partly. For details, refer to the B-EP Series
External Equipment Interface Specification.
[PAUSE]
EURO CODE 20
EURO CODE 21
EURO CODE FE
EURO CODE FF
[FEED]
MAXI CODE TYPE1
MAXI CODE TYPE2
Compatible with the current version (Factory default)
Special specification for specific home delivery company
[PAUSE]
[FEED]
To Next Page
