4. SYSTEM MODE (For Service Persons and System Administrators) EO13-33005
4.9 Interface Setting
4- 81
4.9.2 IrDA Setting
(1) IrDA Communication Program Setting (PROTOCOL)
This setting selects protocol of IrDA.
Notes:
1. When the [FEED] key is pressed, the menu moves in the opposite direction from when the [PAUSE]
key is pressed.
2. When the [FEED] and [PAUSE] keys are simultaneously pressed, the display returns to the system
mode menu.
3. When the [FEED] key or [PAUSE] key is pressed for 0.5 seconds or more during this setting, repeat
mode is enabled and the key pressed is repeatedly entered.
4. When the [POWER] key is pressed, the detailed setting of each interface becomes available on the
LCD.
(2) IrDA Baud Rate setting (SPEED)
Notes:
1. When the [FEED] key is pressed, the menu moves in the opposite direction from when the [PAUSE]
key is pressed.
2. When the [FEED] and [PAUSE] keys are simultaneously pressed, the display returns to the system
mode menu.
3. When the [FEED] key or [PAUSE] key is pressed for 0.5 seconds or more during this setting, repeat
mode is enabled and the key pressed is repeatedly entered.
4. The change in the parameter setting becomes effective when the [POWER] key is pressed after
setting, then stored in the backup memory.
5. For IrCOMM/IrOBEX, the maximum available baud rate is selected.
PROTOCOL IrCOMM
PROTOCOL TEC
[FEED]
[PAUSE]
PROTOCOL OFF
IrCOMM (Factory default)
TEC Protocol
IrDA Disable
SPEED 9600
SPEED 38400
[FEED]
[PAUSE]
SPEED 19200
9600 bps
38400 bps
19200 bps
SPEED 57600
SPEED 115200
115200 bps (Factory default)
57600 bps
To Next Page
