3. ONLINE MODE EO13-33005
3.8 Printer Parameter Fine Adjustment
3- 12
3.8 Printer Parameter Fine Adjustment
This printer paranmeter fine adjustment used to following setting.
LCD Message Description Default Setting
FEED ADJ. Feed Amount Fine Adjustment +0.0mm
X ADJUST X coordinate Fine Adjustment +0.0mm
TONE ADJ. Print Tone Fine Adjustment +0
THRESHOLD<R> Threshold Manual Fine Adjustment
(Black Mark Sensor)
1.0V
THRESHOLD<T> Threshold Manual Fine Adjustment
(Feed Gap Sensor)
1.4V
PEEL ADJ. Strip position Fine Adjustment +0.0mm
PAPER SIZE Paper size for ESC/POS setting 58mm (B-EP2D series),
114mm (B-EP4D series)
For details, refer to System Mode (for service personnel or administrator).
Operation Example
ON LINE
“PAUSE” is displayed.
PAUSE
[PAUSE]
Press the [PAUSE] key.
[PAUSE]
Press and hold the [PAUSE] key for at least 3 seconds.
<1>RESET
The reset menu is displayed.
The printer is turned on, standing by, or printing.
<4>ADJUST SET
[POWER]
System mode menu display (Fine adjustment value setting)
Press the [POWER] key.
FEED ADJ. +0.0mm
[POWER]
Feed amount fine adjustment setting
Press the [POWER] key.
X ADJUST +0
[POWER]
X-coordinate fine adjustment setting
Press the [POWER] key.
Continued to the next page.
TONE ADJUST +0
[POWER]
Print tone fine adjustment setting
Press the [POWER] key.
THRESHOLD<R>1.0V
[POWER]
Reflective sensor manual threshold fine adjustment setting
Press the [POWER] key.
THRESHOLD<T>1.4V
[POWER]
Press the [POWER] key.
PEEL OFF
[POWER]
Strip position fine adjustment setting
Press the [POWER] key.
Transmissive sensor manual threshold fine adjustment setting
When “<1>PARAMETER SET” appears, press the [PAUSE] or [FEED] keys until the
following display appears.
[PAUSE] or [FEED]
To Next Page
