4. SYSTEM MODE (For Service Persons and System Administrators) EO13-33005
4.10 BASIC Setting
4- 113
4.10.3 BASIC File Browser (FILE MAINTENANCE)
This function displays data stored in the BASIC file storage area (00 to 13).
The number of data that can be displayed differs depending on the BASIC file storage area allocated.
Notes:
1. When the [FEED] key is pressed, the menu moves in the opposite direction from when the [PAUSE]
key is pressed.
2.
The above shows the LCD display when there is no data stored. For the LCD display when there is data
stored, please see below.
Example
LCD display when there is stored data:
00 - - - - - - -
[PAUSE]
01 - - - - - - -
[PAUSE]
02 - - - - - - -
11 - - - - - - -
[PAUSE]
12 - - - - - - -
[PAUSE]
13 - - - - - - -
[PAUSE]
[PAUSE]
07 TEST.TEXT
Name of data strored (Max. 12 characters)
Registration No.
To Next Page
