4. SYSTEM MODE (For Service Persons and System Administrators) EO13-33005
4.7 Sensor Display/Adjustment
4- 64
4.7 Sensor Display/Adjustment
In the Sensor Adjustment mode, the status of the sensors and thermistors is displayed. Also you can store
media level voltage and media end level voltage for the Black Mark and Feed Gap.
4.7.1 Sensor Display/Adjustment Operation Example
Strip sensitivity adjustment
Thermal head thermister, ambient thermistor A/D value display
Reflective sensor A/D value display
An asterisk “*” is displayed when the reflective sensor adjustment is completed.
Transmissive sensor A/D value display
[POWER]
[PEEL] AUTO
H:20°C A:+22°C
[REFLECT] 4.5V
[REFLECT] 4.5V*
[TRANS.] 1.8V
<6>SENSOR ADJUST
[POWER]
[PAUSE] or [FEED]
[PAUSE]
[POWER]
An asterisk “*” is displayed when the transmissive sensor adjustment is completed.
[TRANS.] 1.8V*
[PE]R4.5V T1.8V
System mode menu display (Sensor Display/Adjustment)
Reflective sensor/transmissive sensor A/D value without backing paper display
Place a label paper in a manner so that the sensor can detect it.
Hold down the [PAUSE] or [FEED] key for 3 seconds or more.
[PAUSE] or [FEED]
Remove a few labels from the label paper and place the backing paper in a
manner so that the sensor can detect it.
Hold down the [PAUSE] or [FEED] key for 3 seconds or more.
[POWER]
[PE]R4.5V T1.8V*
[PAUSE] or [FEED]
Remove the paper over the sensor.
Hold down the [PAUSE] or [FEED] key for 3 seconds or more.
[POWER]
BATTERY 16.2V
n asterisk “*” is displayed when the sensor adjustment without the baking pape
is completed.
Battery voltage display
[POWER]
BACKLASH1 Ø8
Backlash step count 1 display
[POWER]
BACKLASH2 Ø8
Backlash step count 2 display
<6>SENSOR ADJUST
System mode menu display (Sensor Display/Adjustment)
[POWER]
[POWER]
<0>SHUTDOWN
Hold down the [POWER] key for 3 seconds or more.
[POWER]
Power OFF
System mode menu display (Shutdown)
To Next Page
