4. SYSTEM MODE (For Service Persons and System Administrators) EO13-33005
4.9 Interface Setting
4- 107
(21) 802.11b Baud Rate Setting (802.11b BAUD)
Notes:
1. When the [FEED] key is pressed, the menu moves in the opposite direction from when the [PAUSE]
key is pressed.
2. When the [FEED] and [PAUSE] keys are simultaneously pressed, the display returns to the system
mode menu.
3. When the [FEED] key or [PAUSE] key is pressed for 0.5 seconds or more during this setting, repeat
mode is enabled and the key pressed is repeatedly entered.
4. The change in the parameter setting becomes effective when the [POWER] key is pressed after
setting, then stored in the backup memory.
802.11b BAUD
BAUD RATE 11M
IEEE802.11b baud rate setting
[POWER]
Selected to 11Mbps (Factory default)
[PAUSE]
BAUD RATE 5.5M
Selected to 5.5Mbps
[PAUSE]
BAUD RATE 2M
Selected to 2Mbps
[PAUSE]
BAUD RATE 1M
Selected to 1Mbps
[PAUSE]
To Next Page
