4. SYSTEM MODE (For Service Persons and System Administrators) EO13-33005
4.2 Diagnostic Test
4- 15
(2) Automatic self-test
(*1): Not displayed when the wireless LAN is not installed.
Notes: 1. Print conditions: Label length of 100 mm, direct thermal print mode, no sensors used, one-label
issue.
2. The character “°” used for “°C” may not be printed correctly, depending on the type of the
character code selected.
B-EP2DL-G
MAIN 01JAN2008 V1.0 :A700
BOOT 01JAN2008 V1.0 :2400
SBCS C/G V1.0 :0D00
DBCS JAPANESE V1.0 :0A00
HTML 01JAN2008 V1.0 :AB00
EEPROM OK
SDRAM 16MB
SENSOR1 00000000,00000000
SENSOR2 [H]+20°C [A]+22°C
[R]4.2V [T]2.5V
PE LV. [R]1.8V [T]2.5V
M THRE. [R]1.8V [T]2.5V
BATTERY 16.8V [5]
I/F USB/IrDA/232C
LOOPBACK
IrDA OK
RS-232C NG
BLUETOOTH -
WIRELESS LAN -
WIRELESS LAN VER. (*1)
To Next Page
