700BC–01
B57491
–
WINDSHIELD/WINDOWGLASS/MIRROR
WINDOW DEFOGGER SYSTEM
70–19
2552
Author:
Date:
2002 CAMRY REP
AIR MANUAL (RM881U)
INSPECTION
1.
INSPECT
DEFOGGER RELA
Y
(a)
Inspect the defogger relay (marking: DEF) continuity
.
Standard:
T
erminal
No.
Condition
Specified condition
1
⇔
2
Constant
Continuity
3
⇔
5
Constant
No continuity
3
⇔
5
Apply B+ between
terminals 1 and 2
Continuity
If the continuity is not as specified, replace the relay
.
1089
1091
