030F2–01
03–30
–SERVICE SPECIFICATIONS STARTING & CHARGING
141Author: Date:
2002 CAMRY REPAIR MANUAL (RM881U)
STARTING & CHARGING
SERVICE DATA
2AZ–FE
Starter assy
Specified current
Circle runout Standard
Maximum
Commutator length Standard
Minimum
Brush holder length Standard
Minimum
Snap ring length Maximum
90 A or less at 11.5 V
0.02 mm (0.0008 in.)
0.05 mm (0.0020 in.)
3.3 mm (0.1299 in.)
4.0 mm (0.1575 in.)
9.0 mm (0.3543 in.)
4.0 mm (0.1575 in.)
5.0 mm (0.1969 in.)
Battery
Voltage Standard 12.5 – 12.9 V at 20C (68F)
Generator assy
Rotor coil resistance at 20C (68F)
Slip ring diameter Standard
Minimum
Brush exposed length Standard
Minimum
2.7 – 3.1 Ω
14.2 – 14.4 mm (0.559 – 0.567 in.)
12.8 mm (0.504 in.)
9.5 – 11.5 mm (0.374 – 0.453 in.)
1.5 mm (0.059 in.)
1MZ–FE
Starter assy
Specified current
Circle runout Standard
Maximum
Commutator length Standard
Maximum
Brush holder length Standard
Maximum
Snap ring length
90 A or less at 11.5 V
0.02 mm (0.0008 in.)
0.05 mm (0.0020 in.)
3.3 mm (0.1299 in.)
4.0 mm (0.1575 in.)
9.0 mm (0.3543 in.)
4.0 mm (0.1575 in.)
5.0 mm (0.1969 in.)
Battery
Voltage Standard 12.5 – 12.9 V at 20C (68F)
Generator assy
Rotor coil resistance at 20C (68F)
Slip ring diameter Standard
Minimum
Brush exposed length Standard
Minimum
2.7 – 3.1 Ω
14.2 – 14.4 mm (0.559 – 0.567 in.)
12.8 mm (0.504 in.)
9.5 – 11.5 mm (0.374 – 0.453 in.)
1.5 mm (0.059 in.)
