1
109G–01
A57122
Rear Seat Cushion Pad
Rear Floor Service Hole Cover
Fuel T
ank V
ent T
ube Set Plate
Fuel Suction T
ube Assy W/Pump & Gage
Fuel Pump T
ube Sub–assy
Non–reusable part
N·m (kgf·cm, ft·lbf)
: Specified torque
Fuel Suction T
ube Set Gasket
3.5 (36, 31 in.
⋅
lbf)
–
FUEL
FUEL PUMP ASSY
(1MZ–FE)
1
1–37
1481
Author:
Date:
2002 CAMRY REP
AIR MANUAL (RM881U)
FUEL PUMP ASSY
(1MZ–FE)
COMPONENTS
224
226
