30020–02
F40170
SST
F40171
–DRIVE SHAFT / PROPELLER SHAFT FRONT AXLE LH HUB BOLT
30–27
1981Author: Date:
2002 CAMRY REPAIR MANUAL (RM881U)
FRONT AXLE LH HUB BOLT
REPLACEMENT
HINT:
 COMPONENTS: See page 30–4
 Replace the RH side by the same procedures with LH side.
1. REMOVE FRONT WHEEL
2. DISCONNECT FRONT DISC BRAKE CALIPER ASSY LH(See page 30–21)
3. REMOVE FRONT DISC
4. REMOVE FRONT AXLE LH HUB BOLT
(a) Using SST and a screwdriver or an equivalent to hold, re-
move the front axle LH hub bolt.
SST 09628–10011
5. INSTALL FRONT AXLE LH HUB BOLT
(a) Install a washer and nut to a new front axle LH hub bolt
as shown in the illustration.
(b) Using a screwdriver to hold, install the hub bolt by torqu-
ing the nut.
6. INSTALL FRONT DISC
7. INSTALL FRONT DISC BRAKE CALIPER ASSY LH(See page 30–21)
8. INSTALL FRONT WHEEL
Torque: 103 N⋅m (1,050 kgf⋅cm, 76 ft⋅lbf)
