–SERVICE SPECIFICATIONS ENGINE MECHANICAL
03–21
132Author: Date:
2002 CAMRY REPAIR MANUAL (RM881U)
Part Tightened ft⋅lbfkgf⋅cmN⋅m
Oil pan sub–assy x Cylinder block (See pa
g
e 14–173) 10 mm head 8.0 82 71 in.⋅lbf
Oil
an
sub assy
x
Cylinder
block
(See
age
14 173)10
mm
head
12 mm head
8
.
0
20
82
199
71
in
.
⋅lbf
14
Oil strainer sub–assy x Oil pan sub–assy 8.0 82 71 in.⋅lbf
Oil pan sub–assy No. 2 x Oil pan sub–assy 8.0 82 71 in.⋅lbf
Oil pan drain plug x Oil pan sub–assy No. 2 45 459 33
Water inlet housing x Cylinder block 8.0 82 71 in.⋅lbf
Cylinder head x Cylinder block 12 pointed head 1st
2nd
54
Turn 90
551
Turn 90
40
Turn 90
2nd
Recessed head
Turn 90
19
Turn 90
189
Turn 90
14
Camshaft bearing cap x Cylinder head 16 163 12
Timing belt plate x Oil pump assy 8.0 82 71 in.⋅lbf
Water pump assy x Cylinder block 8.0 82 71 in.⋅lbf
Oil level gage guide x Cylinder block 8.0 82 71 in.⋅lbf
Oil filter union x Cylinder block 30 306 22
Timing belt idler bracket x Cylinder block 28 286 21
Timing belt No. 3 cover x Cylinder head 8.5 87 76 in.⋅lbf
Camshaft timing pulley x Camshaft 125 1,275 92
Timing belt idler sub–assy No. 2 x Timing belt idler bracket 43 438 32
Timing belt idler sub–assy No. 1 x Cylinder block 34 347 25
Chain tensioner assy No. 1 x Oil pump assy 27 280 20
Transverse engine engine mounting bracket x Cylinder block 28 286 21
Timing belt No. 2 cover x Timing belt No. 3 cover 8.5 87 76 in.⋅lbf
Timing belt No. 1 cover x OIl pump assy 8.5 87 76 in.⋅lbf
Crankshaft pulley x Crankshaft 215 2,192 159
Camshaft position sensor x Cylinder head 8.0 82 71 in.⋅lbf
Cylinder head cover x Cylinder head 8.0 82 71 in.⋅lbf
Spark plug x Cylinder head 18 184 13
W/head straight screw plug No. 1 x Cylinder head 44 449 32
W/head straight screw plug No. 2 x Cylinder head 44 449 32
Connecting rod cap x Connecting rod 1st
2nd
25
Turn 90
250
Turn 90
18
Turn 90
Main bearing cap x Cylinder block 12 pointed head 1st
2nd
6 pointed head
22
Turn 90
27
224
Turn 90
275
16
Turn 90
20
Cylinder block w/head straight screw No. 1 plug x Cylinder block 30 306 22
Cylinder block w/head straight screw No. 2 plug x Cylinder block 50 510 37
Cylinder block w/head straight screw No. 3 plug x Cylinder block 30 306 22
Water seal plate x Cylinder block 18 184 13
Cylinder block water drain cock sub–assy x Cylinder block 39 398 29
Vane pump assy x Adjusting strut 43 439 32
Generator x Generator bracket 58 591 43
Generator x Adjusting bar 18 184 13
Intake air surge tank x Intake manifold 43 438 32
Front suspension brace upper x Body 80 816 59
Drive plate & ring gear sub–assy x Crankshaft 83 846 61
Water outlet x Cylinder head 15 153 11
Intake manifold x Cylinder head 15 153 11
EGR pipe No.2 x EGR valve 12 120 9
EGR pipe No.2 x EGR cooler No.1 12 120 9
Exhaust manifold heat insulator No.2 x Exhaust manifold LH 8.5 87 55 in.⋅lbf
EGR cooler No.1 x Cylinder block 9.0 92 80 in.⋅lbf
EGR pipe No.1 x EGR cooler No.1 12 120 9
