TransCore encompass 4 - Table 7-8 Open;Closed Conditions for Output Status

Commands
7-23
D5 2
4 ms output pulse duration
D6 3
2 ms output pulse duration
D7 4
0 ms output pulse duration
D8 4
8 ms output pulse duration
D9 6
0 ms output pulse duration
DA 7
6 ms output pulse duration
DB 1
52 ms output pulse duration
DC 2
28 ms output pulse duration (factory default)
DD 3
00 ms output pulse duration
DE 3
76 ms output pulse duration
DF 7
52 ms output pulse duration
Note: The
first character of the output pulse duration value is alpha; the second char-
acter is numeric.
Table 7-8 shows the output0 and output1 open/closed conditions for
the output status
displays.
Table 7-8 Open/Closed Conditions for Output Status
Output
Status
Output0 Wire Pair Output1 Wire Pair
Orange/Black Brown/Black White/Black Green/Black
O0 Closed Open Closed Open
O1 Open Closed Closed Open
O2 Closed Open Open Closed
O3 Open Closed Open Closed
Table 7-9 shows the output0 and output1 open/closed conditions for
the output status
