Encompass 4 Reader System Guide
4-4
pass 4 Reader tests. Your Encompass 4 Reader is
packaged with the following materi-
als:
• One Encompass 4 Reader
• One mounting bracket and the mounting hardware
• One Encompass 4 Reader Quick Start Guide
• Any accessories ordered as options as shown in Table 4-1
Required accessories are a power/communications cable harness and a 110V AC wall
transformer or a 12V
AC to 18V AC step-up transformer. If you are using an antenna
with the Encompass 4, you also require an Encompass 4 Reader-compatible antenna
and an antenna RF interface. These may be ordered as accessories from TransCore or
obtained from other sources.
Installation Accessory Options
Table 4-1 lists optional TransCore Encompass 4 Reader installation accessory items.
Table 4-1 Installation Accessories
Part No. Description
54-1620-001 Wall or ceiling mount kit
58-1620-001 5-ft connector cable harness
58-1620-002 20-ft connector cable harness
20-1620-003 Connector kit only
56-1620-004 13-pair cable (sold by the foot)
76-1620-005 110V AC to 18V AC Class C transformer
76-1620-006 12V AC to 18V AC step-up transformer
16-4000-002 Encompass 4 Reader System Guide (this man
ual)
Note: The Enc
ompass 4 Reader may be ordered with a multwire cable harness (part
number 58-1620-001 or 58-1620-002 in Table 4-1) as a separate accessory. One end
has a waterproof connector for the Encompass 4 Reader, and the other end has 13
pairs of color-coded wires.
Additional Materials Needed for Testing
You need these additional materials to perform the pre-tests on the Encompass 4
Reader:
• Test tags, supplied by the TransCore dealer or distributor
