Encompass 4 Reader System Guide
7-34
Reader response:
Done
621 Select Predefined Output Control (Factory Default)
Command #621 configures the reader for predefined output mode. In this mode, both
output lines – output0 and output1 – are automatically asserted upon receipt of a valid
unique tag ID. The output line remains asserted for the time specified by output pulse
duration (#67N Set Output Pulse Duration). Any direct control command (#620N
Output Control) automatically disables the predefined output mode.
Note: In W
iegand mode operation, the sense outputs are not controlled by a pre-
defined output mode.
Reader response:
Done
63 Reset Reader
Command #63 resets the power fail bit, clears all buffers, resets tag uniqueness, turns
off both output lines, transmits the sign-on message, and returns to the data mode.
Note: Th
is command does not reset any other configuration parameters.
Reader response:
Model E4 Series Ver X.XX SNSSSSSS
Copyright 2008 TransCore
where
X.XXD Version number
SSSSSS Serial number of the unit, skipping the fourth character printed on
the
reader product label.
640N RF Control
Command #640N directly controls the RF module. The N value controls the RF
power as shown in Table 7-13.
Table 7-13 RF Control Commands
Command RF Power
6400 Turns off RF
6401 Turns on RF
6203
Turn on both output ports
Table 7-12 Output Control Commands (continued)
Command Output Control Option
