TransCore encompass 4 - Tag Data Formats

Encompass 4 Reader System Guide
E-6
a. If desired, in place of 40 six-bit ASCII characters, the AT5707 can support
up to 34 seven-bit ASCII characters.
Tag Data Formats
Tags are programmed at the TransCore factory with the tag model number, date of
manufacture, and data format. Contact TransCore for special order entry procedures
for the format that applies to your system. The following four tag data formats can be
used:
• 10-character alphanumeric ASCII — Four alphanumeric characters are fixed and
can be used to identify either the dealer or the user. The remaining six positions
are numeric and should be unique for each tag issued. For example, the entry
ACME000001 might be specified as the first tag on the order entry form from
ACME Parking Garage.
• 20-character alphanumeric ASCII — Four alphanumeric characters are typically
fixed and the remaining 16 positions are numbered sequentially.
• Wiegand — Tags can be programmed in Wiegand formats with 26 to 54 bits. If
you choose this format, complete a Wiegand format worksheet — attached to the
order entry form — indicating the data to be programmed into the tags.
Note: Security access control tag models can be Wiegand-formatted. SeeTable E-1
through Table E-3 for Wiegand-compatible tag models.
AT5545 Toll 10-yr
battery
20 1 N/A Multifrequency,
sealed case,
metal external
install
AT5547 Toll 5-yr
battery
20 1 N/A Multifrequency,
thin case, non-
metal window
install
AT5704 Trans-
portation
External 4608 256 N/A Multifrequency,
dynamic tag,
metal external
install
AT5707 Trans-
portation
8-yr
battery
40
a
2 N/A 915 MHz
frequency,
dynamic tag,
metal external
install
Table E-3 ATA Protocol Tags (continued)
Tag Model
Number
TagType
Power
Source
Number
of 6-Bit
ASCII
Characters
Number of
128-Bit
Frames
Number of
Wiegand Bits
Special
Features
