Encompass 4 Reader System Guide
8-4
Reader is configured with an integrated antenna, RS–232 and Wiegand communica-
tions, and reads SeGo and IAG protocol tags.
Default Operating Parameter Settings
Table 8-2 contains the factory default configuration settings for the Encompass 4
Reader operating parameters.The default configuration settings may not be the correct
operating configuration settings for a specific site. Changes to the configuration set
-
tings may have to be made, depending on the site plan, as described in Chapter 2,
”Developing the Site Plan” .
Review the default configurations shown in Table 8-2 to determine which parameters,
in addition to operating frequency and operating range, need to be adjusted. Refer to
Chapter 7, ”Commands” for a complete list of parameters and the corresponding
commands.
Note: The dual-protocol Encompass 4 Reader internal timing varies depending on
the operative tag read mode and the type of tag in the read field.
Table 8-2 Encompass 4 Reader Default Configuration Settings
Parameter Setting Command
Operating mode Data 00
Baud rate 9600 1005
Stop bits 1 1010
Parity None 1020
Time and data appended Enabled 302
Auxiliary information appended Disabled 310
Unique ID code criteria Separation of 1 ID 4100
Wiegand mode Disabled 450
Tag translation mode Disabled 452
Multi-tag sort Disabled 454
eGo and eGo Plus tag
initialization during multi-tag sort
Enabled 456
Second alternative group select Disabled 458
Wiegand transmit mode 1 second 4601
Third alternative group select Disabled 490
Fourth alternative group select Disabled 492
Fifth alternative group select Disabled 494
