Encompass 4 Reader System Guide
3-8
Some vehicle windshields contain a metallic treatment that could
prevent an interior
windshield-mounted tag from being read. However, many of these metallized wind-
shields have areas that are not
metallized. On a vehicle without open areas in its met-
allized windshield, you might need to insta
ll an Encompass 4 Reader-compatible LPT
on the vehicle. See the section “Installing eGo Plus License Plate Tags” on page 3-13.
Contact TransCore for more information. See the section “Technical Support” on page
9-7.
Required Materials
You need the following supplies to install an eGo Plus Sticker Tag:
• Glass cleaner, mild detergent and water, or any cleaning solution appropriate for
your windshield
• Clean, dry cloth
• eGo Plus Sticker Tag
Positioning eGo Plus Sticker Tags
TransCore designed the eGo Plus Sticker Tag to be installed on the upper center or
upper corner portion of the windshield. Figure 3-6, Figure 3-7, and Figure 3-8 illus-
trate possible upper center tag
placement locations. If the upper portion of the
windshield is tinted with an aftermarket conductive tint, use placement shown in
Figure 3-7.
Mirror Post Attached on Windshield
Choose this placement option as shown in Figure 3-6 if the mirror post is attached on
the windshield.
Figure 3-6 eGo Plus Sticker Tag Placement
Mirror Post Attached on Header
Choose this placement option if the mirror post is attached on the header as shown in
Figure 3-7 or if the upper portion of the windshi
eld is tinted with a conductive tint.
