Command Quick Reference
D-3
Appendix D
Command Quick Reference
This appendix lists the default configuration settings for the
Encompass
®
4 Reader and its commands. Commands are listed both
numerically and alphabetically.
Command Syntax
The command numbers consist of from 2 to 4 hex digits. The letters N or S may follow
a command number. The letter N indicates that part of the command number is vari
-
able. The letter S indicates the requirement for an alphanumeric data string that is to
be included immediately following the command number. Hex digits (0–9, A–F) in
either uppercase or lowercase characters may be used in data strings and for hex digits
A–F. For more information see
Chapter 5, “General Software Information.
Table D-1 lists factory default settings. Table D-2 on page D-5 lists, in numerical
order, all of the commands available to users. Table D-3 on page D-17 lists the same
commands by command name.
Factory Default Settings
Note: Table D-1 lists the factory default settings for the Encompass 4 Reader.
Table D-1 Encompass 4 Reader Default Configuration Settings
Parameter Setting Command
Operating mode Data 00
Baud rate 9600 1005
Stop bits 1 1010
Parity None 1020
Time and data appended Enabled 302
Auxiliary information appended Disabled 310
Disable EAC page append Disabled 320
Unique ID code criteria Separation of 1 ID 4100
Valid ID code criteria Acquisition of 1 ID 4200
