Encompass 4 Reader System Guide
D-8
491 Enable third alternate group
select
Done
492 Disable fourth alternate group
select
Done
493 Enable fourth alternate group
select
Done
494 Disable fifth alternate group
select
Done
495 Enable fifth alternate group select Done
496 Disable alternate group select Done
497 Enable alternate group select Done
505 Display version Model [model]
Ver [version no.] SN [serial no.]
506 Display hardware configuration
information
S...S
S...S = ASCII string
(maximum length of 20
characters)
510 Display RF transceiver FPGA
version
RF FPGA VER = XX.XX
511 Display RF transceiver I filter chip
version
FIL IC I VER = XX.XX
512 Display RF transceiver Q filter
chip version
FIL IC Q VER = XX.XX
513 Display DSP board Actel version DSP FPGA VER = XX.XX
520 Display power fail bit PWRB Px R0
P0 = no power fail has occurred
P1 = power fail has occurred
R0 = not applicable
521 Display reader ID number RDID xx
xx = 00–FF
Table D-2 Encompass 4 Reader Commands Listed Numerically (continued)
Number Command Name Reader Message
