VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
86 02.9704.6010 0
Front Gobo Bulkhead with Iris Assembly
21.9704.6505 Rev. C
Refer to Figure 3-40
No. Item Qty. UM. Description
1 10.9704.0218 1 EA SENSOR BRACKET, GOBO WHEEL 2
2 10.9704.0693 2 EA CLAMP, CONN, 5 DRIVER BOARD
3 10.9704.6234 1 EA BULKHEAD, FRONT, GOBO MODULE
4 21.9704.6272 1 EA ASSY, IRIS MODULE
5 24.9678.3240 1 EA BD ASSY, GOBO POSITION
6 24.9704.2901 2 EA PCB ASSY, 5 WAY MOTOR DRIVER
7 53.6520.0001 6 EA SCREW, 4-40 X 3/8" PPZ
8 53.6558.0009 4 EA SCREW, 6-32 X 3/8" LG PPZ SEMS
9 53.6596.0002 1 EA SCREW, 4-40 X 5/16" LG PPZ SEMS
10 53.6601.0003 1 EA SCREW, 4-40 X 3/16" PFZ UNDERCUT
11 55.2203.0001 4 EA SCREW, 4-40 X 1/4" PPZ
12 55.6818.0002 2 EA STANDOFF, 45-DEG NYLOK KURLY-LOK
