ENCLOSURE ASSEMBLY : FRONT PANEL ASSEMBLY
02.9704.6010 0 129
3
Front Panel Assembly
21.9704.0825 Rev. G
Refer to Figure 3-61
No. Item Qty. UM. Description
1 10.9679.0850 1 EA BACKING PLATE, NEUTRIK
2 11.9704.0846 1 EA DISPLAY OVERLAY
3 10.9704.1815 1 EA FRONT PANEL
4 21.9704.0880 1 EA ASSY, MCB/DISPLAY
5 10.9704.0886 1 EA MCB BRACKET MOUNT
6 10.9704.1826 1 EA PAN ASSY, SUPPORT BRACKET
7 24.9664.4895 1 EA PCB ASSY, DMX INPUT
8 25.9704.0830 1 EA POWERCON, NEUTRIK AC INPUT CONNECTOR NAC3MPX
9 53.6598.0001 6 EA SCREW, 4-40 X 3/8" PFB
10 53.6558.0007 1 EA SCREW, 6-32 X 1/4" PPZ SEMS
11 53.5636.0375 2 EA SCREW, 6-32 X 3/8" PFSS-B
12 55.2288.0001 2 EA STANDOFF, MF 6-32 X 13/16" LG, 1/4 HEX
13 46-9704.0853 1 EA USB PORT, PANEL MOUNT
