AC Input
Data In
Data Thru
Menu Display
Used to input manual
commands, program, test,
set defaults and access
internal status information.
Input Panel Components
Head Assembly
Houses color system, gobos, animation
wheel, strobe, iris and optics mechanisms
Backcap Assembly
Provides access to lamp for replacement
and provides controls for beam adjustment.
Yoke Assembly
Houses Master Control
Board (MCB), tilt motor,
ignitor, and cooling fans.
Input Panel
Provides DMX In and Thru,
and AC Power connections.
(see detail below)
Upper Enclosure Assembly
Houses power supply, PFC,
lamp driver, pan motor
assembly, and display board.
