HEAD ASSEMBLY : GOBO WHEEL 1 ASSEMBLY
02.9704.6010 0 77
3
Gobo Wheel 1 Assembly
21.9704.0211 Rev. D
Refer to Figure 3-34
Note: For included gobos, refer to “Included Items Kit, VL4000 BeamWash” on page 35.
No. Item Qty. UM. Description
1 10.9704.0219 1 EA HUB, GOBO WHEEL
2 10.9704.0228 1 EA PULLEY, DRIVEN, GOBO WHEEL 1 INDEX
3 10.9704.0229 1 EA CAP, HUB, GOBO WHEEL 1
4 10.9704.0236 1 EA DRIVEN PULLEY, GOBO ROTATE
5 22.9704.0220 1 EA PLATE ASSY, ROTATING GOBO WHEEL
6 22.9704.0222 1 EA SUN GEAR, GOBO ROTATE WITH MAGNET
7 53.6659.0015 3 EA SCREW, 2-56 X 1/4" PFB
8 53.6659.0023 3 EA SCREW, 2-56 X 3/16" PFZ
9 53.6659.0027 4 EA SCREW, 2-56 X 5/16" PFZ
10 54.1259.0014 1 EA BEARING, TORQUE TUBE, 1.313 OD
11 54.9687.1253 3 EA BEARING, NPB, MR105ZZK13
12 55.2256.0001 1 EA MAGNET, 2:17 SMCO 2MM X 2MM X3MM
13 - AR EA LOCTITE #242, REMOVABLE (BY OTHERS)
14 10.9678.0250 1 EA MAGNET TAPE (NOT SHOWN)
