Vari Lite VL4000 - Pan Module Assembly

ENCLOSURE ASSEMBLY : PAN MODULE ASSEMBLY
02.9704.6010 0 135
3
Pan Module Assembly
21.9704.1820 Rev. G
Refer to Figure 3-69
No. Item Qty. UM. Description
1 54.1255.0001 1 EA BEARING ASSY, BLACK FLUSH MOUNT
2 54.9698.0224 1 EA BELT, TIMING, S2M 210GRV 15 MM WIDE URTH/KVLR
3 10.9704.1867 1 EA BRIDGE, BELT TENSION ROLLERS
4 53.6505.0022 2 EA CARRIAGE BOLT, 3/8"-16 X 3/4"
5 53.2200.0008 6 EA NUT, 8-32 KEPS SS
6 53.2019.0004 2 EA NUT, 3/8-16 X 0.500" LG X HD GRADE 5 BLK
7 10.9704.3821 1 EA PAN MOTOR, PLATE
8 10.9704.1866 1 EA PLATE, BELT TENSION, PAN
9 22.9704.3820 1 EA PULLEY / MOTOR ASSY
10 10.9704.0766 2 EA ROLLER, TENSION ADJUST, TILT
11 53.6682.0026 2 EA SCREW, 8-32 X 3/4" LG PPZ SEMS
12 53.6682.0025 4 EA SCREW, 8-32 X 5/8" PPZ SEMS
13 53.6539.0001 2 EA WASHER, 3/8" SPLIT LOCK
