Vari Lite VL4000 - Color Module Assembly

HEAD ASSEMBLY : COLOR MODULE ASSEMBLY
02.9704.6010 0 91
3
Color Module Assembly
21.9704.7400 Rev. C
Refer to Figure 3-42, Figure 3-43 and Figure 3-44
No. Item Qty. UM. Description
1 10.9704.0406 5 EA GUIDE ROD, COLOR FLAG
2 10.9704.0407 5 EA SLIDE, COLOR FLAG
3 10.9704.0408 5 EA SLIDE, COLOR FLAG, OPPOSITE
4 10.9704.0410 5 EA PULLEY, DRIVE, COLOR FLAG
5 10.9704.0434 4 EA STANDOFF, BULKHEAD, FIXED COLOR WHEEL
6 10.9704.0461 1 EA MOUNT, DRIVER BOARD, COLOR BULKHEAD
7 10.9704.0499 3 EA STANDOFF, BOARD STACK, COLOR
8 10.9704.0693 2 EA CLAMP, CONN, 5 DRIVER BOARD
9 10.9704.4417 6 EA GLIDE SPACER, COLOR FLAG
10 10.9704.4438 1 EA PLATE, COLOR MIX MODULE
11 10.9704.5415 1 EA GUIDE SUPPORT, COLOR FLAG, MAIN, STIFFENER
12 10.9704.5418 3 EA SPACER, 0.172" ID, 0.31" OD, 0.115" LG
13 10.9704.6451 1 EA BRACKET, LEFT, COLOR BULKHEAD
14 10.9704.6452 1 EA BRACKET, RIGHT, COLOR BULKHEAD
15 21.9704.0411 1 EA ASSY, BELT, 210GRV
16 21.9704.0412 4 EA ASSY, BELT, 240GRV
17 21.9704.0415 1 EA ASSY, FIXED COLOR WHEEL
18 21.9704.0420 1 EA ASSY, CROSS-FLOW BLOWER, COLOR COOLING
19 21.9704.0440 1 EA ASSY, SENSOR BOARD, COLOR FLAGS
20 21.9704.0431 1 EA ASSY, STROBE, LEFT
21 21.9704.5443 5 EA ASSY, COLOR BELT IDLER
22 22.9704.4401 5 EA ASSY, GLIDE, COLOR FLAG
23 22.9704.5401 1 EA ASSY, GUIDE, COLOR FLAG STIFFENER
24 22.9704.5470 1 EA ASSY, DIMMER FLAG, FRONT
25 22.9704.5480 1 EA ASSY, DIMMER FLAG, REAR
26 22.9704.6472 2 EA ASSY, MAGENTA FLAG
27 22.9704.6474 2 EA ASSY, CYAN FLAG
28 22.9704.6476 2 EA ASSY, YELLOW FLAG
29 22.9704.6478 2 EA ASSY, CTO FLAG
30 24.9698.1231 1 EA PCB ASSY, SENSOR
31 24.9704.2901 2 EA PCB ASSY, 5-WAY MOTOR DRIVER
