HEAD ASSEMBLY : CONCURRENT ANIMATION WHEEL ASSEMBLY
02.9704.6010 0 83
3
Concurrent Animation Wheel Assembly
21.9704.6353 Rev. E
Refer to Figure 3-38
No. Item Qty. UM. Description
1 10.9704.0240 1 EA SPACER, 0.197" ID, 0.250" OD, 0.032" THK
2 10.9704.0319 1 EA FLAG, ANIMATION ARM
3 10.9704.0372 6 EA SPACER, ROLLER, SHUTTER ROTATE
4 10.9704.0373 5 EA SPACER, ROLLER, SHUTTER ROTATE
5 10.9704.0375 1 EA SHIELD, BELT, ANIMATION
6 10.9704.1311 1 EA ARM, ANIMATION WHEEL
7 10.9704.2323 1 EA DRIVE PULLEY, ANIMATION WHEEL
8 10.9704.6248 1 EA SPACER, 0.197" ID, 0.250" OD, 0.128" THK
9 10.9704.6317 1 EA INDEX PULLEY, ARM
10 21.9704.0332 1 EA MOTOR ASSY, ANIMATION WHEEL 2
11 22.9704.6343 1 EA ASSY, CONCURRENT ANIMATION
12 53.6559.0001 3 EA SCREW, 4-40 X 1/4" PFZ
13 53.6578.0002 2 EA SCREW, 6-32 X 3/16" SET CUP PNT
14 53.6650.0001 1 EA SCREW, 2-56 X 5/16" PPZ
15 53.6659.0006 1 EA SCREW, 2-56 X 3/16" PPZ
16 53.6659.0012 4 EA SCREW, 2-56 X 1/8" PPZ
17 53.6659.0015 4 EA SCREW, 2-56 X 1/4" PFB
18 54.1259.0021 1 EA BEARING, FLANGE, 0.250" OD, 0.500" ID, 0.188" W
19 54.9687.1253 2 EA BEARING, NPB, MR105ZZK13
20 54.9704.0392 1 EA BELT, TIMING, MXL, 225 GRV, 0.125" WD, SILICONE/KEV
21 54.9704.1575 4 EA BEARING, SR188, 0.250" ID, 0.500" OP, 0.125" WD
22 55.3301.0003 1 EA WASHER, FLAT #2 AN ID 0.099 X O
23 55.6669.0156 1 EA STANDOFF, 1/4" HEX 2-56 5/32" L FF ZINC
