VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
30 02.9704.6010 0
VL4000 BeamWash Luminaire (Part 3)
Figure 3-3: VL4000 BeamWash Luminaire Subassembly Drawing Tree Part 3
VL4000 Lamp Base & Tip Fan
Extension Cable Assembly
25.9704.1602 Rev. B
Continued from “VL4000 BeamWash Luminaire (Part 2)” on page 29.
VL4000 Color Power Distribution
Cable Assembly
25.9704.0708 Rev. D
VL4000 Tilt with Shield Cable
Assembly
25.9704.2717 Rev. B
VL4000 BeamWash Power Dist Cable
Assembly
25.9704.6705 Rev. D
VL4000 Main from MCB Data Cable
Assembly
25.9704.6713 Rev. B
VL4000 Main to Bulkheads Data
Cable Assembly
25.9704.6714 Rev. B
LVS Chassis Ground Cable Assembly
25.9687.0025 Rev. A
VL4000 Pan / Tilt Cable Assembly
25.9704.1703 Rev. D
VL4000 Enclosure PFC Input Cable
Assembly
25.9704.1800 Rev. A
VL4000 DMX Cable Assembly
25.9704.0802 Rev. A
VL4000 USB Interface Cable
Assembly
25.9704.0804 Rev. A
VL4000 Thermal Control Cable
Assembly
25.9704.1805 Rev. A
VL4000 Chassis to Yoke Cable
Assembly
25.9704.0716 Rev. B
VL4000 BeamWash Generic
Luminaire Assembly
21.9704.6010 Rev. C
VL4000 Pan / Power Distribution
Input Cable Assembly
25.9704.2704 Rev. A
VL4000 Enclosure PFC Output Cable
Assembly
25.9704.1801 Rev. A
VL4000 Ballast Control Cable
Assembly
25.9704.0803 Rev. A
Upper Enclosure Assembly
21.9704.0800 Rev. Y
VL4000 BeamWash Inlet Fan
Extension Cable Assembly
25.9704.6601 Rev. B
VL4000 Ballast to Ignitor Cable
Assembly
25.9704.1702 Rev. A
Upper Enclosure Cover Assembly
21.9704.0850 Rev. A
