Vari Lite VL4000 - Yoke Assembly Yoke Assembly

YOKE ASSEMBLY : YOKE ASSEMBLY
02.9704.6010 0 113
3
Yoke Assembly
Yoke Assembly
21.9704.6700 Rev. B
Refer to Figure 3-56
No. Item Qty. UM. Description
1 10.9704.0736 1 EA SAFETY PLATE, PAN
2 10.9704.0743 1 EA BRACE, TILT LOCK
3 10.9704.0751 1 EA ROD, PAN LOCK
4 10.9704.0753 4 EA LEVER, PAN/TILT LOCK
5 10.9704.0754 4 EA SPRING, PAN/TILT LOCK
6 10.9704.0768 4 EA STANDOFF, TILT MOTOR
7 10.9704.1719 1 EA BASE REINFORCEMENT, YOKE
8 10.9704.1751 1 EA ROD, TILT LOCK, LONG
9 10.9704.1752 2 EA LOCKING PIN, TILT LOCK
10 10.9704.1865 1 EA ADAPTER, PAN TUBE
11 21.9704.1765 1 EA ASSY, TILT MOTOR, DOUBLE ROLLERS
12 22.9704.6705 1 EA ASSY, YOKE FRAME
13 24.9704.1126 1 EA PCB ASSY, IGNITOR, 1200W
14 24.9704.1908 1 EA TILT MOTOR DRIVER
15 52-0406 2 EA #THERM PAD, VO GAP PAD ULT-SOFT 0.45 X 0.625
16 53.5560.0250 6 EA SCREW, SET 8-32 X 1/4" L
17 53.6517.0002 7 EA SCREW, 10-32 X 3/8" PPB SEMS
18 53.6525.0001 4 EA SCREW, 6-32 X 5/16" PPZ
19 53.6546.0002 3 EA SCREW, 8-32 X 5/16" PPZ
20 53.6558.0009 4 EA SCREW, 6-32 X 3/8" LG PPZ SEMS
21 53.6575.0008 14 EA SCREW, 8-32 X 1/4" PPZ SEMS
22 53.6587.0001 8 EA SCREW, 4-40 X 1/8" PPZ
23 53.6608.0001 12 EA SCREW, 6-32 X 3/8" PFB
24 55.2132.0012 2 EA STANDOFF, 1/4" HEX 6-32 X 0.75" L
25 55.2178.0001 2 EA CABLE ANCHOR MOUNT, #8 SCREW
26 55.2288.0001 4 EA STANDOFF, MF 6-32 X 13/16" LG 1/4" HEX
27 55.6597.0003 3 EA CABLE CLIP, SELF RETAINING, 1/8" THK PNL
28 55.6659.0007 4 EA STANDOFF, 1/4 HEX 6-32 0.250" LG MF ALUM
