COMPONENTS : HEAD AND YOKE COMPONENTS
02.9704.6010 0 7
1
Head and Yoke Components
The following illustration shows the major sub-assemblies which are located in the luminaire head and
yoke assemblies.
Yoke Arm Cover
Yoke Arm
Contains fixed color wheels,
dimmer mechanism, strobe
Color Module Assembly
mechanism, CYM color mixer
Cover
and CTO color correction.
Head Cover
(attached by tether)
Head Cover
(attached by tether)
Enclosure Assembly
see page 8
Houses lenses
and optics mechanisms.
Optics Assembly
Gobo/Animation Assembly
Contains two rotating gobo / effects wheels,
one rotating animation wheel, and iris
mechanism
Backend Assembly
Houses lamp, reflector, and
UV/IR assembly.
