Vari Lite VL4000 - VL4000 Beamwash Luminaire (Part 6)

DRAWING TREES : VL4000 BEAMWASH LUMINAIRE (PART 6)
02.9704.6010 0 33
3
VL4000 BeamWash Luminaire (Part 6)
Figure 3-6: VL4000 BeamWash Luminaire Subassembly Drawing Tree Part 6
Continued from “VL4000 BeamWash Luminaire (Part 1)” on page 28.
Color Module Assembly
21.9704.7400 Rev. C
210 Groove Belt Assembly
21.9704.0411 Rev. B
240 Groove Belt Assembly
21.9704.0412 Rev. B
Control Belt Idler Assembly
21.9704.5443 Rev. B
Left Strobe Assembly
21.9704.0431 Rev. G
240 Groove Belt Assembly
21.9704.0412 Rev. B
Cross-Flow Blower Assembly
21.9704.0420 Rev. E
Fixed Color Wheel Assembly
21.9704.0415 Rev. G
Fixed Color Wheel 1 Assembly
21.9704.0430 Rev. D
Fixed Color Wheel 2 Assembly
21.9704.0435 Rev. E
Fixed Color Motor Assembly
21.9704.0419 Rev. A
VL4000 Color A to Color B Cable
Assembly
25.9704.0712 Rev. A
VL4000 Color Bulkhead 3 Cable
Assembly
25.9704.0402 Rev. A
VL4000 Color Bulkhead 2 Cable
Assembly
25.9704.0401 Rev. A
Right Strobe Assembly
21.9704.0432 Rev. D
VL4000 Color Bulkhead 1 Cable
Assembly
25.9704.0400 Rev. A
VL4000 Data Network Extension
Cable Assembly
25.9704.0711 Rev. B
Color Flags Sensor Board
Assembly
21.9704.0440 Rev. B
VL4000 Color Bulkhead 4 Cable
Assembly
25.9704.0403 Rev. A
