HEAD ASSEMBLY : GOBO/ANIMATION MODULE ASSEMBLY
02.9704.6010 0 71
3
Gobo/Animation Module Assembly
21.9704.6200 Rev. E
Refer to Figure 3-30, Figure 3-31, Figure 3-32, and Figure 3-33
No. Item Qty. UM. Description
1 04.9704.0203 1 EA DIPSWITCH LABEL, GOBO BOARD C
2 04.9704.0204 1 EA DIPSWITCH LABEL, GOBO BOARD D
3 21.9698.0330 1 EA ASSY, DAMPER, MOTOR SHAFT 5MM COMPRISED OF:
3a 10.9698.0335 1 EA DAMPER, MOTOR SHAFT 5 MM
3b 53.6604.0500 1 EA SCREW, 4-24 X 1/2" PPB, HI-LO
4 10.9704.0223 4 EA DRIVE PULLEY, GOBO WHEEL
5 10.9704.0249 1 EA SPACER, MOTOR, SIZE 15
6 10.9704.0270 1 EA COOLING DUCT, GOBO BULKHEAD, TOP
7 10.9704.0271 1 EA COOLING DUCT, GOBO BULKHEAD, BOTTOM
8 10.9704.0272 1 EA COVER, COOLING DUCT, GOBO BULKHEAD
9 10.9704.0290 1 EA CLAMP, CONNECTOR, SENSOR BOARD
10 10.9704.0323 3 EA STANDOFF, ANIMATION MODULE, SHORT, #6-32
11 10.9704.1233 1 EA PULLEY 16 GROOVE, ANIMATION ARM DRIVE
12 10.9704.6231 2 EA BLOCK SPACER, EDGE, GOBO BULKHEAD
13 10.9704.6245 1 EA BULKHEAD, MIDDLE, GOBO MODULE
14 10.9704.6251 1 EA BULKHEAD, LEFT, GOBO BULKHEAD
15 10.9704.6252 1 EA BULKHEAD, RIGHT, GOBO BULKHEAD
16 17.9704.0906 1 EA PCB ASSY, WHEEL POSITION SENSOR
17 21.9704.0211 1 EA ASSY, GOBO WHEEL 1
18 21.9704.0212 1 EA ASSY, GOBO WHEEL 2
19 21.9704.0230 1 EA ASSY, SENSOR, GOBO 1 INDEX
20 21.9704.0260 1 EA ASSY, SENSOR, GOBO 2 INDEX
21 21.9704.6353 1 EA ASSY, ANIMATION WHEEL, CONCURRENT
22 21.9704.6505 1 EA ASSY, IRIS BULKHEAD
23 22.9704.0261 1 EA SHAFT ASSY, GOBO WHEEL 1
24 22.9704.0264 1 EA SHAFT ASSY, GOBO WHEEL 2
25 23.9704.0005 1 EA FAN ASSY, VL4000 INLET AND GOBO
- 25.9704.6200 1 EA CABLE ASSY, VL4000 BW GOBO BULKHEAD, CABLE 1
- 25.9704.6201 1 EA CABLE ASSY, VL4000 BW GOBO BULKHEAD, CABLE 2
- 25.9704.0711 3 EA CABLE ASSY, VL4000 DATA NETWORK EXTENSION
26 44.9704.0209 1 EA MOTOR, SIZE 15, 5 X 17 MM SHAFT
