Gobo/Animation Module Assembly (continued)
Figure 3-31: Gobo/Animation Module Assembly (Part 2)
21
*APPLY LOCTITE 242 TO THREADS PRIOR TO INSTALLATION.
34 (x3)
47
36 (x2)
3
11*
32
See Detail
Item 3 Detail
3b
3a
