Vari Lite VL4000 - VL4000 Beamwash Generic Luminaire Assembly

TOP ASSEMBLY : VL4000 BEAMWASH GENERIC LUMINAIRE ASSEMBLY
02.9704.6010 0 39
3
VL4000 BeamWash Generic Luminaire Assembly
21.9704.6010 Rev. C
Refer to Figure 3-9
No. Item Qty. UM. Description
1 04.9704.0137 1 EA LABEL, LAMP CHANGE, 1200W FASTFIT
2 10.9704.0706 1 EA BEARING SPACER, SHORT
3 10.9704.0707 1 EA PULLEY, DRIVEN, TILT
4 10.9704.0711 1 EA TILT STOP
5 10.9704.0734 2 EA COVER MOUNT, YOKE ARM
6 10.9704.1712 2 EA TILT BEARING HOLDER
7 10.9704.1733 1 EA COVER, YOKE BASE
8 10.9704.1742 1 EA TILT LOCK CYLINDER
9 10.9704.2733 4 EA COVER MOUNT, YOKE ARM
10 21.9704.0800 1 EA ASSY, UPPER ENCLOSURE, 1200W/1400W
11 21.9704.1767 1 EA ASSY, STABILIZER
12 21.9704.6600 1 EA ASSY, HEAD FRAME
13 21.9704.6700 1 EA ASSY, YOKE
- 25.9704.1602 1 EA CABLE ASSY, VL4000 FAN EXT, LAMP BASE & TIP (not shown)
- 25.9704.0708 1 EA CABLE ASSY, VL4000 PWR DIST OUTPUT, COLOR (not shown)
- 25.9704.2717 1 EA CABLE ASSY, VL4000 TILT WITH SHIELD (not shown)
- 25.9704.6705 1 EA CABLE ASSY, VL4000 BW PWR DIST OUTPUT MAIN (not shown)
- 25.9704.6713 1 EA CABLE ASSY, VL4000 DATA, MAIN FROM MCB (not shown)
- 25.9704.6714 1 EA CABLE ASSY, VL4000 BW DATA, MAIN TO BLKHDS (not shown)
- 25.9687.0025 1 EA CABLE ASSY, SVL ENCLOSURE TO YOKE CHASSIS GND (not shown)
- 25.9704.6601 1 EA CABLE ASSY, VL4000 BW INLET FAN EXT (not shown)
- 25.9704.1702 1 EA CABLE ASSY, VL4000 BALLAST TO IGNITOR (not shown)
14 53.2202.0008 4 EA NUT, 8-32 HEX SS NYLON INSERT
15 53.5910.0375 6 EA SCREW, 10-32 X 1/2", PPSS TYPE F
16 53.6517.0625 5 EA SCREW, 10-32 X 5/8" PPZ
17 53.6521.0500 3 EA SCREW, 8-32 X 1/2" SOCKET, FLATHEAD, ALLOY STEEL
18 53.6525.0001 1 EA SCREW, 6-32 X 5/16" PPZ
19 53.6546.0002 4 EA SCREW, 8-32 X 5/16" PPZ
20 53.6552.0011 16 EA SCREW, 8-32 X 1/4" PFZ
21 53.6575.0010 2 EA SCREW, 8-32 X 1/2" PPZ SEMS
22 54.9687.0250 2 EA BEARING, 68072RS
23 54.9698.0224 1 EA BELT, TIMING, S2M 210GRV 15MM WIDE URTH/KVLR
