VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
98 02.9704.6010 0
Fixed Color Wheel Assembly
21.9704.0415 Rev. G
Refer to Figure 3-47
No. Item Qty. UM. Description
1 21.9704.0430 1 EA ASSY, FIXED COLOR WHEEL 1
2 21.9704.0435 1 EA ASSY, FIXED COLOR WHEEL 2
3 21.9704.0419 2 EA ASSY, MOTOR, FIXED COLOR
4 54.9698.0002 1 EA BELT, TIMING, MXL, 150 GR 0.125" W URETH/KEV
5 54.9704.0390 1 EA BELT, TIMING, MXL, 106 GR 0.125" W URETH/KEV
6 10.9704.0427 1 EA BULKHEAD, FIXED COLOR WHEELS
7 22.9704.1430 1 EA CER LENS ASSY, FIXED COLOR
8 10.9704.0290 2 EA CLAMP, CONNECTOR, SENSOR BOARD
9 10.9704.0223 2 EA DRIVE PULLEY, GOBO WHEEL
10 17.9704.0904 2 EA PCB ASSY, WHEEL POSITION SENSOR
11 53.6559.0001 2 EA SCREW, 4-40 X 1/4" PFZ
12 53.6601.0004 3 EA SCREW, 4-40 X 1/8" PFZ, UNDERCUT
13 53.6601.0003 4 EA SCREW, 4-40 X 3/16" PFZ, UNDERCUT
14 53.6601.0002 2 EA SCREW, 4-40 X 3/16" PTZ
15 53.6659.0003 4 EA SCREW, 2-56 X 3/8" PPZ
16 53.6558.0001 2 EA SCREW, 6-32 X 3/8" PPZ
17 53.6513.0030 2 EA SCREW, M3 X .5 X 14 MM LG PFZ METRIC
18 53.5559.0250 4 EA SCREW, 6-40 X 0.25" CONE POINT
19 10.9704.0424 2 EA SHAFT, FIXED COLOR WHEEL
20 55.6659.0009 2 EA SPACER, #4 ID, 0.250" OD, 0.094" LG
