Drawing Trees
VL4000 BeamWash Luminaire (Part 1)
Figure 3-1: VL4000 BeamWash Luminaire Subassembly Drawing Tree Part 1
VL4000 BeamWash Luminaire
20.9704.0002 Rev. A
Included Items Kit, VL4000
BeamWash
28.9704.0002 Rev. C
(note, this item includes all included/
standard gobos)
VL4000 BeamWash Generic
Luminaire Assembly
21.9704.6010 Rev. C
Color Module Assembly
21.9704.7400 Rev. C
Gobo/Animation Module
Assembly
21.9704.6200 Rev. E
VL4000 BeamWash Head Cover
Assembly
22.9704.6670 Rev. A
VL4000 BeamWash Yoke Arm
Cover Assembly
22.9704.6732 Rev. A
Yoke Assembly
21.9704.6700 Rev. B
Double Rollers Tilt Motor Assembly
21.9704.1765 Rev. B
Head Frame Assembly
21.9704.6600 Rev. B
Stabilizer Assembly
21.9704.1767 Rev. A
Continued on “VL4000
BeamWash Luminaire (Part 2)”
on page 29.
Continued on “VL4000
BeamWash Luminaire (Part 2)”
on page 29.
Continued on “VL4000
BeamWash Luminaire (Part 4)”
on page 31.
Continued on “VL4000
BeamWash Luminaire (Part 6)”
on page 33.
Back Cover Assembly
21.9704.6671 Rev. A
Tilt Belt Tension Rollers Assembly
21.9704.1760 Rev. A
Tilt Motor with Pulley Assembly
21.9704.0764 Rev. A
