HEAD ASSEMBLY : GOBO WHEEL 2 ASSEMBLY
02.9704.6010 0 79
3
Gobo Wheel 2 Assembly
21.9704.0212 Rev. F
Refer to Figure 3-35
Note: For included gobos, refer to “Included Items Kit, VL4000 BeamWash” on page 35.
No. Item Qty. UM. Description
1 10.9704.0219 1 EA HUB, GOBO WHEEL
2 10.9704.0236 1 EA DRIVEN PULLEY, GOBO ROTATE
3 10.9704.1216 1 EA SUN GEAR, GOBO ROTATE
4 22.9704.0207 1 EA DRIVEN PULLEY WITH MAGNET, GOBO WHEEL 2 INDEX
5 22.9704.0220 1 EA PLATE ASSY, ROTATING GOBO WHEEL
6 53.6659.0023 7 EA SCREW, 2-56 X 3/16" PFZ
7 53.6659.0027 3 EA SCREW, 2-56 X 5/16" PFZ
8 54.1259.0014 1 EA BEARING, TORQUE TUBE, 1.313 OD
9 54.9687.1253 3 EA BEARING, NPB, MR105ZZK13
10 55.2256.0001 1 EA MAGNET, 2:17 SMCO 2MM X 2MM X3MM
11 - AR EA LOCTITE #242, REMOVABLE (NOT SHOWN - BY OTHERS)
12 10.9678.0250 1 EA MAGNET TAPE (NOT SHOWN)
