Vari Lite VL4000 - VL4000 Beamwash Luminaire (Part 2)

DRAWING TREES : VL4000 BEAMWASH LUMINAIRE (PART 2)
02.9704.6010 0 29
3
VL4000 BeamWash Luminaire (Part 2)
Figure 3-2: VL4000 BeamWash Luminaire Subassembly Drawing Tree Part 2
Head Frame Assembly
21.9704.6600 Rev. B
Continued from “VL4000 BeamWash Luminaire (Part 1)” on page 28.
Edge Lens Motor Assembly
21.9704.6185 Rev. E
Zoom Lens Motor Assembly
21.9704.6195 Rev. D
Back End Assembly
21.9704.6615 Rev. F
Upper Enclosure Assembly
21.9704.0800 Rev. Y
Side Mount Fan Assembly
21.9704.0810 Rev. E
Front Panel Assembly
21.9704.0825 Rev. G
VL4000 AC Input Connector
Assembly
25.9704.0830 Rev. A
Side Mount Filter Holder Assembly
21.9704.2815 Rev. C
Pan Bearing / Pulley Assembly
21.9704.0840 Rev. F
Pan / Fan Driver Board Assembly
21.9704.0870 Rev. G
Continued on “VL4000
BeamWash Luminaire (Part 3)”
on page 30.
Pan Module Assembly
21.9704.1820 Rev. G
Continued on “VL4000
BeamWash Luminaire (Part 3)”
on page 30.
VL4000 BeamWash Generic
Luminaire Assembly
21.9704.6010 Rev. C
5mm Motor Shaft Damper Assembly
21.9704.0330 Rev. B
5mm Motor Shaft Damper Assembly
21.9704.0330 Rev. B
Lenticular with Motors Assembly
21.9704.6310 Rev. C
Lenticular Arm Assembly
21.9704.6315 Rev. B
Slotted Optical Switch
25.9687.0020 Rev. A
VL4000 BeamWash Optics Assembly
21.9704.6150 Rev. D
Continued on “VL4000
BeamWash Luminaire (Part 5)”
on page 32.
