VARI❋LITE - VL4000 BEAMWASH LUMINAIRE SERVICE MANUAL
56 02.9704.6010 0
Lenticular with Motors Assembly
21.9704.6310 Rev. C
Refer to Figure 3-20
No. Item Qty. UM. Description
1 10.9704.0240 1 EA SPACER, 0.197" ID, 0.250" OD, 0.032" THK
2 10.9704.1233 1 EA PULLEY, 16 GRV, 0.125" WD, ANIMATION ARM DRIVE
3 10.9704.6315 1 EA MOTOR MOUNT, LENTICULAR
4 10.9704.6318 2 EA SPACER, 0.125" ID, 0.250" OD, 0.046" THK
5 10.9704.6323 1 EA DRIVE PULLEY, LENTICULAR
6 10.9704.6325 2 EA ARM STOP MOUNT
7 10.9704.6340 1 EA SPACER, OPTICS, 0.198" ID, 0.250" OD, 0.082" THK
8 21.9704.6239 1 EA ASSY, TENSION ADJUSTMENT ROLLER, COMPRISED OF:
8a 10.9704.6237 1 EA PLATE, TENSION ADJUST, ANIMATION WHEEL
8b 10.9704.6238 1 EA ROLLER, TENSION ADJUST, ANIMATION WHEEL
8c 53.6601.0002 1 EA SCREW, 4-40 X 3/16" PTZ
9 21.9704.6315 1 EA ASSY, ARM, LENTICULAR
10 24.9704.6314 1 EA SENSOR BOARD, INDEX
11 25.9687.0020 1 EA SWITCH, SLOTTED OPTICAL
12 44.9687.1209 1 EA MOTOR SIZE-17, SHAFT 0.70"
13 44.9704.0217 1 EA MOTOR SIZE-17, 24MM SHAFT, SHORT STACK
14 53.6513.0002 4 EA SCREW, M3 X 5MM, PFZ
15 53.6578.0002 4 EA SCREW, 6-32 X 3/16", SET, CUP PNT
16 53.6596.0001 1 EA SCREW, 4-40 X 5/16" PPZ
17 53.6596.0002 3 EA SCREW, 4-40 X 5/16" LG PPZ SEMS
18 53.6682.0002 2 EA SCREW, 4-40 X 1/4, PPZ, SEMS
19 54.9704.5317 1 EA BELT, TIMING, MXL, 200 GRV, 0.125" WD, SILICONE/KEV
20 54.9704.6316 1 EA BELT, TIMING, MXL, 135 GRV, 0.125" WD, URETH/KEV
21 55.2179.0009 1 EA CABLE ANCHOR MOUNT, #4 SCREW
22 55.9704.6305 2 EA STANDOFF, 3/16" HEX, 4-40 X 7/32", F-F
23 55.6738.0005 0.85 IN. TUBING, SILICONE, 4MM ID, 8MM, OD, SOFT RED, (0.425")
