Vari Lite VL4000 - Head Assembly; Head Frame Assembly

HEAD ASSEMBLY : HEAD FRAME ASSEMBLY
02.9704.6010 0 47
3
Head Assembly
Head Frame Assembly
21.9704.6600 Rev. B
Refer to Figure 3-14
No. Item Qty. UM. Description
1 04.9704.6699 2 EA LABEL, FAN LABEL BLACKOUT
2 10.9704.0640 2 EA GUIDE, MODULE, HEAD
3 10.9704.0701 2 EA TILT TUBE
4 21.9704.6150 1EAASSY, OPTICS
5 21.9704.6615 1 EA ASSY, BACK END, BEAMWASH
6 22.9704.1629 1 EA ASSY, VL4K TILT MAGNET
7 22.9704.6605 1 EA ASSY, SIDE RAIL, RIGHT
8 22.9704.6608 1 EA ASSY, SIDE RAIL, LEFT
9 23.9704.0003 4 EA FAN ASSY, VL4000 LAMP TIP AND BASE
10 24.9704.2909 1 EA BOARD, 12V REGULATOR/DISTRO
11 53.5655.0251 4 EA SCREW, 6-20 X 1/4" PFZ THREAD FORMING
12 53.6545.0003 4 EA SCREW, 8-32 X 3/8" PFZ
13 53.6552.0001 8 EA SCREW, 8-32 X 1/2" PFZ
14 53.6552.0011 1 EA SCREW, 8-32 X 1/4" PFZ
15 53.6558.0009 1 EA SCREW, 6-32 X 3/8" LG PPZ SEMS
16 53.6575.0008 1 EA SCREW, 8-32 X 1/4" PPZ SEMS
17 53.6575.0010 3 EA SCREW, 8-32 X 1/2" PPZ SEMS
18 53.6596.0001 4 EA SCREW, 4-40 X 5/16" PPZ
19 53.6682.0022 4 EA SCREW, 8-32 X 3/8" PPZ SEMS
20 55.6576.0001 8 EA SCREW, #10-16 X 3/8" TYPE B PPZ
21 55.6775.0011 3 EA BUSHING, SNAP, 0.609 ID, 0.75 MT HOLE, BLACK
